Built to Handle Real Terrain

Estimated Dry Weight - Front 15.5 lbs

Estimated Dry Weight - Rear 90 lbs

Overall Length 66"

Overall Height 20"

Overall Width 15.5"

Model Track (9397S)

Length 129"

Width 10"

Pitch 2.86"

Lug Height 2.5"

Rail Spacing 5.5"

Chassis Carbon fiber

Chain Slider Standard POM

Automatic Chain Tensioner Standard POM

Brake System Custom billet caliper, dual piston

Master Cylinder Use OEM

Syncrodrive Belt Drive System Mitsubishi 28 mm width, 896 mm length

Quick Access Belt Drive LEXAN

Drive Chain DID520VOX, 62 link

Drive Shaft 1 1/16" hex, titanium, 7 tooth anti-ratchet sprocket

Drive Shaft Sprocket 16 tooth - splined

Upper Syncrodrive Belt Drive Gear 41 tooth - splined

Lower Syncrodrive Belt Drive Gear 47 tooth - splined

Hardware & Fasteners Titanium, anodized aluminum & stainless steel

Front & Rear Shock Elka Shock Stage 3

Rear Suspension 6061-T6 Aluminium reactor arms

Adjustable limiter strap

Front Suspension Arm Powder coated steel with STRENX reinforcements

Adjustable limiter strap

Rear Max Travel 16.0" (40.64 cm)

Strut Fully adjustable soft strut

Ski Design Parabolic design, 20" radius

Ski Length 42" (106.68 cm)

Ski Material UHMW

Skag Type Hardox, zinc plated

Estimated Dry Weight - Front 15.5 lbs

Estimated Dry Weight - Rear 99 lbs

Overall Length 62"

Overall Height 20"

Overall Width 16"

Model Track (9460S)

Length 120"

Width 12"

Pitch 2.86"

Lug Height 2.6"

Rail Spacing 5.5"

Chassis Carbon fiber

Chain Slider Standard POM

Automatic Chain Tensioner Standard POM

Brake System Hayes V32 dual piston caliper, shielded rotor with anti-rattle pad clip

Master Cylinder Hayes pre-bled, right hand, 11 mm piston

Syncrodrive Belt Drive System Mitsubishi 28 mm width, 896 mm length

Quick Access Belt Drive LEXAN

Drive Chain DID520VOX, 62 link

Drive Shaft 1 1/16" hex, titanium, 7 tooth anti-ratchet sprocket

Drive Shaft Sprocket 16 tooth - splined

Upper Syncrodrive Belt Drive Gear 41 tooth - splined

Lower Syncrodrive Belt Drive Gear 47 tooth - splined

Hardware & Fasteners Titanium, anodized aluminum & stainless steel

Front & Rear Shock Elka Shock Stage 3

Rear Suspension 6061-T6 Aluminium reactor arms

Front Suspension Arm Powder coated steel with STRENX reinforcements

Rear Max Travel 16.0" (40.64 cm)

Strut Fully adjustable soft strut

Ski Design Parabolic design, 20" radius

Ski Length 42" (106.68 cm)

Ski Material UHMW

Skag Type Hardox, zinc plated

Estimated Dry Weight - Front 15.5 lbs

Estimated Dry Weight - Rear 102 lbs

Overall Length 66"

Overall Height 20"

Overall Width 16"

Model Track (9459S)

Length 129"

Width 12"

Pitch 2.86"

Lug Height 2.6"

Rail Spacing 5.5"

Chassis Carbon fiber

Chain Slider Standard POM

Automatic Chain Tensioner Standard POM

Brake System Hayes V32 dual piston caliper, shielded rotor with anti-rattle pad clip

Master Cylinder Hayes pre-bled, right hand, 11 mm piston

Syncrodrive Belt Drive System Mitsubishi 28 mm width, 896 mm length

Quick Access Belt Drive LEXAN

Drive Chain DID520VOX, 62 link

Drive Shaft 1 1/16" hex, titanium, 7 tooth anti-ratchet sprocket

Drive Shaft Sprocket 16 tooth - splined

Upper Syncrodrive Belt Drive Gear 41 tooth - splined

Lower Syncrodrive Belt Drive Gear 47 tooth - splined

Hardware & Fasteners Titanium, anodized aluminum & stainless steel

Front & Rear Shock Elka Shock Stage 3

Rear Suspension 6061-T6 Aluminium reactor arms

Front Suspension Arm Powder coated steel with STRENX reinforcements

Rear Max Travel 16.0" (40.64 cm)

Strut Fully adjustable soft strut

Ski Design Parabolic design, 20" radius

Ski Length 42" (106.68 cm)

Ski Material UHMW

Skag Type Hardox, zinc plated

Estimated Dry Weight - Front 15.5 lbs

Estimated Dry Weight - Rear 99 lbs

Overall Length 64"

Overall Height 20"

Overall Width 16"

Model Track (9463S)

Length 126"

Width 12"

Pitch 3.5"

Lug Height 3.25"

Rail Spacing 5.5"

Chassis Carbon fiber

Chain Slider Standard POM

Automatic Chain Tensioner Standard POM

Brake System Custom billet caliper, quad piston

Master Cylinder Custom pre-bled, right hand, adjustable lever, mineral oil

Syncrodrive Belt Drive System Mitsubishi 28 mm width, 896 mm length

Quick Access Belt Drive LEXAN

Drive Chain DID520VOX, 62 link

Drive Shaft 1 1/16" hex, titanium, 7 tooth anti-ratchet sprocket

Drive Shaft Sprocket 16 tooth - splined

Upper Syncrodrive Belt Drive Gear 41 tooth - splined

Lower Syncrodrive Belt Drive Gear 47 tooth - splined

Hardware & Fasteners Titanium, anodized aluminum & stainless steel

Front & Rear Shock Fox Float 3 EVOL QS3-QSR

Rear Suspension The "ONE" 6061-T6 Billet Aluminium, ride height adjustable

Front Suspension Arm 6061-T6 Billet Aluminium Trellis Long Travel with adjustable limiter strap

Rear Max Travel 16.0" (40.64 cm)

Strut Fully adjustable soft strut

Ski Design Parabolic design, 20" radius

Ski Length 42" (106.68 cm)

Ski Material UHMW

Skag Type Hardox, zinc plated

Estimated Dry Weight - Front 15.5 lbs

Estimated Dry Weight - Rear 104 lbs

Overall Length 73"

Overall Height 20"

Overall Width 16"

Model Track (9458S)

Length 137"

Width 12"

Pitch 2.86"

Lug Height 2.6"

Rail Spacing 5.5"

Chassis Carbon fiber

Chain Slider Standard POM

Automatic Chain Tensioner Standard POM

Brake System Hayes V32 dual piston caliper, shielded rotor with anti-rattle pad clip

Master Cylinder Hayes pre-bled, right hand, 11 mm piston

Syncrodrive Belt Drive System Mitsubishi 28 mm width, 896 mm length

Quick Access Belt Drive LEXAN

Drive Chain DID520VOX, 62 link

Drive Shaft 1 1/16" hex, titanium, 7 tooth anti-ratchet sprocket

Drive Shaft Sprocket 16 tooth - splined

Upper Syncrodrive Belt Drive Gear 41 tooth - splined

Lower Syncrodrive Belt Drive Gear 47 tooth - splined

Hardware & Fasteners Titanium, anodized aluminum & stainless steel

Front & Rear Shock Elka Shock Stage 3

Rear Suspension 6061-T6 Aluminium reactor arms

Front Suspension Arm Powder coated steel with STRENX reinforcements

Rear Max Travel 16.0" (40.64 cm)

Strut Fully adjustable soft strut

Ski Design Parabolic design, 20" radius

Ski Length 42" (106.68 cm)

Ski Material UHMW

Skag Type Hardox, zinc plated
